Fanuc M20iA Mate+ integration with molding machine

Our standard integration with molding machines from any producer includes:

  • Robot Fanuc M20iD/25 Mate+ with 25kg payload and 1831mm range
  • End effector signals: Output: 1x vacuum, 1x blow-off, 4x DO; Input: 1x vacuum check, 5x DI
  • Dual Check Safety (DCS)
  • Euromap 67 configuration
  • Safety fance made with solid, transparent polycarbonate
  • Safety equipment (door lock, relays, E-STOP)
  • Conveyor belt
  • Extended warranty 24 months





EXTRA ROBOT OPTIONS:

  • FIPA Quick change SR150-A-SL with safety-lock and electric plug mounted on robot flange
  • Robotic conduit with all cables attached (from axis 1 to 6)
  • Valve island (2x vacuum, 4x valve 5/3) with Ethernet IP bus node mounted in box attached to 3rd axis of the robot
  • Ethernet IP input node (16DI) mounted in box attached to 3rd axis of the robot



EXTRA TOOLING AND PHERIPHERALS:

  • Gripping system for part picking / insert placing / sprue cutting
  • System of insert feeding and positioning
  • Sprue cutting station (pneumatic cutting / hot blade cutting / laser cutting / ultrasonic cutting)
  • Assembling station (mechanical pushing / ultrasonic welding / laser welding)
  • Vision system for quality inspection
  • Labeling station
  • Test stations
