Suction fingers for vacuum cups – rigid

  • Components for mounti ng vacuum cups
  • Two vacuum ports

Suction fingers for vacuum cups – swivel

  • Components for mounting vacuum cups
  • Angle adjustment +/- 90°

Suction fingers – swivel, lightweight design

  • Adjustable head for mounting and aligning vacuum cups with part contours
  • Angle adjustment +/- 100°
  • Up to 50 % less weight compared to standard version
  • Heads are interchangeable with the heads of elbow arms GR02.240 - GR02.242, GR02.250 - GR02.252, GR02.260 - GR02.262

Spring compensated gripper arm for vacuum cups

  • Spring compensates for variation in ejection stroke
  • Smooth motion due to lubrication-free polymer bearing
  • Only for round vacuum cups

Spring compensated gripper arm for vacuum cups – non-rotating

  • Spring compensates for variation in ejection stroke
  • Smooth motion due to lubrication-free polymer bearing
  • Suitable for round, oval and rectangular vacuum cups
  • Lateral vacuum port or at the end

Spring compensated suction fingers for vacuum cups – non-rotating, swivel

  • Adjustable head for mounting and aligning vacuum cups with part contours
  • Spring compensates for variation in ejection stroke
  • Smooth motion due to lubrication-free polymer bearing
  • Angle adjustment +/- 120°

Swivelling unit – universal, double-acting

  • Space-saving lateral application of vacuum cups to the workpiece
  • Double-acting, controlled swivel movement and short duty cycles
